BOLTIGHT® – HYDRAULIC BOLT TENSIONERS
A pioneer in hydraulic bolt tensioning for over a decade, Boltight is at the forefront of manufacturing fast, precise, and safe tightening tools for simultaneously tightening and loosening multiple bolts.
The hydraulic bolt tensioners from this subsidiary of the Nord-Lock group represent a cutting-edge solution for hydraulic bolt tightening.
The challenge of large assemblies: essential precision.
The larger the size of the bolts, the more critical the mechanical stresses become. An approximate preheating can lead to gradual loosening, leaks, or even complete equipment failure. In these environments where reliability is essential, operators cannot afford to make mistakes. However, conventional torque tightening methods do not always achieve uniform tension across all the bolts.
Boltight : mastering hydraulic tension.
To address this issue, Boltight offers a hydraulic tensioner technology based on axial elongation. This method relies on the application of controlled hydraulic pressure, allowing the bolt to be temporarily elongated. The nut is then screwed on effortlessly, ensuring a consistent, precise, and reproducible preload.
This process offers several tangible advantages:
- TIdentical tension on each bolt, eliminating load discrepancies
- Significant reduction in intervention time
- No unwanted torque
- Enhanced safety for operators
- Increased long-term reliability
Boltight® Product Range
TSR+ Tensioners
Equipped with a mechanism based on a return spring, which ensures automatic retraction of the piston after the system is depressurized at the end of the tightening sequence, the TSR+ tensioners have been designed to enhance productivity and operator safety.
Standard Bolt Tensioners
Designed to fit most ANSI B16.5, MSS SP44, and API 17D flanges, they are compatible with both metric and imperial bolts ranging from ¾” (M20) to 4” (M100).
Hydraulic Closure Systems
Ideal for applications in electricity generation and the oil and gas industry, this tool is designed to maintain assemblies.
It is compatible with existing turbine bodies and studs, providing a quick, uniform, and safe method for checking turbine clearances.
Typhoon+ Tensioners
Developed to meet the technical and environmental requirements of the wind energy market, where bolts are heavily loaded and often have restricted access.
Standard Bolt Tensioners
Specifically configured for this type of application, they feature a nickel-plated outer surface that allows them to withstand the high initial stress of the bolt.
Hydraulic Nuts
Hydraulic nuts allow for easy tightening and precise preload of large-diameter bolts. A hydraulic pump activates the internal lifting system, so the effort required to tighten a very large diameter bolt is reduced to the effort needed to operate the pump.
How Hydraulic Bolt Tensioning Works ?
Boltight solutions allow for the simultaneous tightening and loosening of multiple bolts using high-pressure hydraulic force.
The bolt tensioners elongate the bolt before the nut descends below zero friction, ensuring extreme precision, speed, uniformity, and safety in any bolting situation.
- A tensioner is attached to a bolt or stud.
- High-pressure hydraulic force is used to extend the bolt in the axial direction.
- The elongation of the bolt creates the clamping force, while the bolt is extended, causing the nut to lift relative to the flange.
- An access window in the tensioner allows the nut to be screwed on with very little friction.
- When the hydraulic pressure is released, the nut captures the extension in the bolt, retaining the load.
Why Trust Boltight?
- Over 20 Years of Experience in Hydraulic Tensioning
- Recognized Expertise in the Most Demanding Sectors
- High-Quality Manufacturing, Compliant with International Standards
- Customized Solutions Based on Your Technical Constraints
- Technical Support and Guidance at Every Stage of the Project
